Blackmagic MultiView 4 is a multi viewer that lets you monitor 4 completely independent SDI video sources on a single display! Featuring 4 6G-SDI inputs with full re-synchronization, MultiView 4 lets you monitor any combination of SD, HD and Ultra HD video formats and frame rates all at the same time. Blackmagic MultiView 4 can output to both 1080 HD and 2160p Ultra HD displays so you connect it to either regular HD or Ultra HD televisions. If you connect an Ultra HD television or monitor, you can take advantage of the extra resolution of Ultra HD and see full resolution 1920 x 1080 HD in each view for incredible sharpness! You can even turn on audio meter overlays, custom labels and more in each view!
Blackmagic Design MultiView 4 Specs
Interfaces
| Output Connectors | 1 x BNC (6G-SDI) 1 x HDMI 4 x BNC (6G-SDI, Looping) |
| Other I/O | 1 x RJ45 1 x USB Type-A USB 2.0 |
Standards
| Video Standard Compliance | SMPTE 259M/292M/296M/310M/425M-B ITU -R BT.601/BT.656 |
| Reclocking | Yes |
Transmission
| Video Format | SDI (10-Bit 4:4:4/4:2:2 RGB, YUV) DCI 4K: 24 fps UHD 4K: 23.98/24/25/29.97/30 fps DCI 2KPsF: 23.98/24/25 fps DCI 2K: 23.98/24/25 fps 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF: 23.98/24/25/29.97/30 fps 1080i: 50/59.94/60 fps 720p: 50/59.94/60 fps NTSC: 29.97 fps PAL: 25 fps |
| Maximum Sampling Rate | 48 kHz / 24-Bit |
| Maximum Data Rate | 6 Gb/s |
Power
| Power Consumption | 90 to 240 VAC (16 W) |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 113°F / -20 to 45°C |
| Operating Humidity | 0 to 90% |
General
| Rack Form Factor | 1 RU |
| Dimensions | 6.7 x 5.5 x 1.8″ / 17.0 x 14.0 x 4.5 cm |
| Weight | 1.28 lb / 0.58 kg |
Packaging Info
| Package Weight | 2.08 lb |
| Box Dimensions (LxWxH) | 9.05 x 7.8 x 2.4″ |
